MAIN FEATURES

• LEDs on front of panel for signaling operating status and alarms
• AUTOMATIC - 0 (standby) - MANUAL pushbuttons (fixed or pulse)
• Anti-seize autotest (can be disabled)
• Dry running protection with: level probes/ floats/ pressure switches
• Up to 4 control inputs: floats/pressure switches
• Clicson inputs with automatic reset (can be disabled)
• Inversion of inputs (from normally open to normally closed)
• Start/stop float switch function (can be disabled)
• Current protection delay
• Automatic reset from minimum current alarm (can be disabled)
• Delay time of motor enabling after power mains return
• Pushbutton for manual operation (fixed or pulse)
• Predisposition for run capacitors for single-phase version (not included)

ADDITIONAL FUNCTIONS SMART PRO 2

• Duty/standby (can be disabled)
• Immediate motor changeover in case of a fault

VERSIONS

• Power supply 1phase 100-240Vac 50/60Hz
• Power supply 3phase 310-450Vac 50/60Hz

CONTROLS

• Electronic control of maximum current with assisted calibration
• Electronic control of minimum current (dry running) with assisted calibration
• Failure or incorrect phase sequence control on power supply input (can be disabled)

ALARMS

• Alarms reported: voltage status, levels, motor overload, minimum motor current, clicson motor
• General alarm output contacts

PROTECTIONS

• Auxiliary and motor protection fuses
• Isolator (except for NB code)
• Box in ABS, IP55
