* Image is indicative. The actual product may differ in appearance.
CL110 SET OF 2 TEMPERATURE AND HUMIDITY
SEMS59443
Out of stock
€311.14 / PCS
Unit of measure: PCS
Brand:
Tags:
| Range of product | Harmony XB5R |
|---|---|
| Product or component type | Wireless transmitter |
| Device short name | XB5R |
| Transmission frequency | 2400 MHz |
| Antenna type | Omnidirectional |
| Max power consumption in W | 60 mW |
|---|---|
| Number of channels | 16 |
| Modulation Technique | O-QPSK |
| Bandwidth | 5 MHz |
| Antenna gain | 0 dBi |
| CAD overall height | 21 mm |
| CAD overall width | 40 mm |
| CAD overall depth | 40 mm |
| Product weight | 0.034 kg |
| Measurement temperature | 90 °C |
| Mechanical robustness | Free fall resistance 1000 mm conforming to IEC 60068-2-32 |
| Standards | IEC 61010-1 UL 61010-1 IEEE 802.15.4 |
| Radio agreement | ANATEL ARIB T66 FCC ICASA RSS SRRC |
| Communication port protocol | Zigbee green power at 2.4 GHz conforming to IEEE 802.15.4 |
| Maximum sensing distance | 100 m in free field 25 m transmitter in a plastic box type XAL D and receiver in a metal enclosure 10 m transmitter in box type XAL D, receiver in metal enclosure and use relay-antenna |
| Acquisition time | 2 ms |
| Response time | < 2 ms |
| Fixing mode | Magnetic fixing |
| Mounting mode | Magnetic |
| Electrical composition code | PW1 |
| Ambient air temperature for storage | -40…70 °C |
|---|---|
| Ambient air temperature for operation | -40…70 °C |
| Relative humidity | 10…95 % at -40…70 °C |
| IP degree of protection | IP54 conforming to IEC 60529 |
| IK degree of protection | IK06 conforming to IEC 62262 |
| Shock resistance | 40 gn (duration = 6 ms) for 3 shocks conforming to IEC 60068-2-27 20 gn (duration = 16 ms) for 1000 shocks conforming to IEC 60068-2-27 10 gn (duration = 11 ms) for 3 shocks conforming to IEC 60068-2-27 |
| Vibration resistance | 2 gn (f= 5…200 Hz) conforming to IEC 60068-2-6 4 gn (f= 200…500 Hz) conforming to IEC 60068-2-6 1 gn (f= 10…2000 Hz) conforming to IEC 60068-2-64 1 gn (f= 5…500 Hz) conforming to IEC 60068-2-6 |
| Electromagnetic compatibility | Susceptibility to electromagnetic fields - test level: 25 V/m (80 MHz...6 GHz) conforming to IEC 61000-4-3 Susceptibility to conducted disturbances - test level: 20 V (0.15...80 MHz) conforming to IEC 61000-4-6 Electromagnetic field immunity test - test level: 1000 A/m (pulsed) conforming to IEC 61000-4-8 Electromagnetic field immunity test - test level: 300 A/m (continuous) conforming to IEC 61000-4-8 Electromagnetic field immunity test - test level: 1000 A/m (pulsed) conforming to EN/IEC 61000-4-9 Damped oscillatory wave - test level: 3 kV conforming to IEC 61000-4-10 Damped oscillatory wave - test level: 2.5 kV conforming to EN/IEC 61000-4-18 Surge immunity test conforming to EN/IEC 61000-4-18 Surge immunity test (common mode) conforming to IEC 61000-4-5 Immunity to conducted RF disturbances - test level: 30 V (differential mode) conforming to IEC 61000-4-5 Immunity to conducted RF disturbances (continuous) conforming to IEC 61000-4-16 Immunity to conducted RF disturbances - test level: 300 V Immunity to conducted RF disturbances (short term) conforming to IEC 61000-4-16 |
| Product certifications | CSA CCC UL GOST C-Tick BT 2006/95/EC |
| Directives | 2004/108/EC - electromagnetic compatibility 1999/5/EC - R&TTE directive |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.5 cm |
| Package 1 Width | 4.5 cm |
| Package 1 Length | 9.0 cm |
| Package 1 Weight | 62.0 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 100 |
| Package 2 Height | 30.0 cm |
| Package 2 Width | 30.0 cm |
| Package 2 Length | 40.0 cm |
| Package 2 Weight | 6.569 kg |
| Country of origin | ID |
|---|
| Warranty (in months) | 18 |
|---|
